Part Number:WS023-1
Product Reviews:

Availability:

In Stock
£14.35 (£11.96 Ex VAT)
Unit Quantity: Pair
Description

A pair of cables to suit Garador C-type canopy doors manufactured between 1999-2002, with a side extension spring on each side of the door and vertical tracks. The door will have a cast bracket at the top corner of the door with a white nylon pulley angled at approximately 45 degrees.

Not for use with old doors with concealed springs (Mk3F and F3C models manufactured pre-1999).

  • Garador current part number: 1157
  • Garador old part number. SG230-17
  • Compatible part: Cost saving alternative
Fitting Instructions

Click the PDF icon to open the printable fitting instructions for Garador C-type cables.

C Type Cables



SAFETY NOTES:
The spring is under tension. Please follow instructions carefully to avoid injury.

Wear protective gloves and eye protection.

GARADOR C-TYPE CABLES


STEP 1
Open the door approximately 6" and place a block under it to keep it open.

STEP 2
Remove the e-clip (arrow 1) and slide the roller spindle towards the centre of the door (arrow 2).

STEP 3
Thread the large loop of cable over the plastic roller (arrow 3).

STEP 4
Slide the roller spindle back to its original position (arrow 4).

STEP 5
Refit the e-clip (arrow 5).

STEP 6
Ensure the cable is located in the grooved slot of the roller spindle (arrow 6).

STEP 7
Thread the opposite end of the cable through the spring assembly as shown in Fig 2. Then locate the spring back in the plastic guide channel.

STEP 8
Holding the mid loop of the cable, slide the spring up the guide channel until you can attach the mid loop to the S hook at the top of the track.

STEP 9
Fit the cable around the pulley wheel on the top corner bracket (refer to the opposite side of the door for location of cable).

STEP 10
Prop the door in the open position and refit the spring.

GARADOR C-TYPE CABLES


Specification
Cable Length 1676 mm
Cable Diameter 1.5 mm
